Application prospects of active balancing in multi-module battery packs

Dmytro Lipko; Arsenii Naidonov; Yuliia Kozhushko; Yuliia  Bondarenko; Pavlo Safronov; Oleksandr  Bondarenko

doi:10.15222/TKEA2025.3-4.47

Dmytro Lipko Igor Sikorsky Kyiv Polytechnic Institute, Ukraine https://orcid.org/0000-0001-8232-3249
Arsenii Naidonov Igor Sikorsky Kyiv Polytechnic Institute, Ukraine https://orcid.org/0000-0003-2410-1693
Yuliia Kozhushko Igor Sikorsky Kyiv Polytechnic Institute, Ukraine https://orcid.org/0000-0002-4045-4088
Yuliia Bondarenko Igor Sikorsky Kyiv Polytechnic Institute, Ukraine https://orcid.org/0000-0002-1803-0684
Pavlo Safronov Igor Sikorsky Kyiv Polytechnic Institute, Ukraine https://orcid.org/0000-0002-5708-4933
Oleksandr Bondarenko Igor Sikorsky Kyiv Polytechnic Institute, Ukraine https://orcid.org/0000-0002-4276-1145

DOI: https://doi.org/10.15222/TKEA2025.3-4.47

Keywords: battery, battery management system (BMS), active balancing, imbalance, electric vehicle (EV), driving range, lifetime

Abstract

In modern batteries, particularly those used in electric vehicles, one of the key factors determining efficiency, reliability, and durability is the imbalance of charge levels (state of charge, SoC) between cells. This imbalance arises due to technological heterogeneity of cells, differences in internal resistance, degradation levels (state of health, SoH), temperature gradients, measurement errors in control channels, and unequal cooling conditions. The imbalance leads to reduced usable capacity, increased thermal loads, and uneven current distribution during charging and discharging, which ultimately lowers efficiency and shortens battery lifetime. Previous studies highlight the potential of active balancing to mitigate charge-level imbalance in multi‑module batteries.
The aim of this work is to experimentally verify the effectiveness of active balancing, determine its impact on imbalance levels and energy efficiency indicators of multi‑module lithium‑ion batteries, and formulate practical recommendations for the use of active balancers in electric transport systems. The study showed that applying an active balancer to a module with degraded cells reduced the maximum imbalance from 220 mV to 45 mV, increased usable capacity from 33 Ah to 43 Ah, improved the estimated SoH from 69% to 81%, and extended the real driving range of the electric vehicle by 56% (from 82 km to 128 km when discharged from 100% to 10% SoC).
The experimental data confirm that local active balancing is an effective and economically feasible approach to restoring usable capacity, improving energy efficiency, and extending the service life of traction batteries without requiring full‑scale balancing of all modules. This approach is promising for practical implementation in electric transport systems and stationary energy storage, particularly for operational restoration of batteries with heterogeneous degradation levels.

References

H. S. Hemavathi, “Overview of cell balancing methods for Li-ion battery technology,” Energy Storage, vol. 3, p. e203, 2021, doi: 10.1002/est2.203.

Z. B. Omariba, L. Zhang, and D. Sun, “Review of Battery Cell Balancing Methodologies for Optimizing Battery Pack Performance in Electric Vehicles,” IEEE Access, vol. 7, pp. 129335–129352, 2019, doi: 10.1109/ACCESS.2019.2940090.

X. Liu, W. Li, X. Guo, B. Su, S. Guo, Y. Jing, and X. Zhang, “Advancements in Energy-Storage Technologies: A Review of Current Developments and Applications,” Sustainability, vol. 17, no. 18, Art. no. 8316, 2025, doi: 10.3390/su17188316.

S. Li, C. Zhang, Y. Zhao, Y. Liu, Z. Chen, Y. Chen, et al., “Effect of thermal gradients on inhomogeneous degradation in lithium-ion batteries,” Communications Engineering, vol. 2, p. 74, 2023, doi: 10.1038/s44172-023-00124-w.

A. Ashraf, B. Ali, M. S. A. Al Sunjury, and P. Tricoli, “A Comprehensive Review of the Art of Cell Balancing Techniques and Trade-Offs in Battery Management Systems,” Energies, vol. 18, no. 13, p. 3321, 2025, doi: 10.3390/en18133321.

E. Fraccaroli, S. Jang, L. Stach, et al., “To Balance or to Not? Battery Aging-Aware Active Cell Balancing for Electric Vehicles,” arXiv preprint arXiv:2401.03124, Jan. 2024, doi: 10.48550/arXiv.2401.03124.

O. Bondarenko, and D. Lipko, “Using partial charge-discharge cycle of battery to increase its lifespan,” Technology and Design in Electronic Equipment, no. 3–4, pp. 9–15, 2023, doi: 10.15222/TKEA2023.3-4.09.

O. Bondarenko, and D. Lipko, “Modified active balancer for use in multi-module batteries,” Technology and Design in Electronic Equipment, no. 1–2, pp. 11–23, 2024, doi: 10.15222/TKEA2024.1-2.11.

N. Khan, C. A. Ooi, A. Alturki, M. Amir, Shreasth, and T. Alharbi, “A critical review of battery cell balancing techniques, optimal design, converter topologies and performance evaluation for optimizing storage system in electric vehicles,” Energy Reports, vol. 11, pp. 4999–5032, 2024, doi: 10.1016/j.egyr.2024.04.041.

D. Lipko, and O. Bondarenko, “Development of a DC-DC Converter for Active Battery Balancing Systems in a Format of Student Competition,” Microsystems, Electronics and Acoustics, pp. 316127.1–316127.8, Dec. 2024, doi: 10.20535/2523-4455.mea.316127.

D. Lipko, and O. Bondarenko, “Modified Active Balancer for Multi-Module Battery Pack,” in Proc. 19th Biennial Baltic Electronics Conf. (BEC), Tallinn, Estonia, 2024, pp. 1–5, doi: 10.1109/BEC61458.2024.10737985.

J. Cao, B. Xia, and J. Zhou, “An Active Equalization Method for Lithium-ion Batteries Based on Flyback Transformer and Variable Step Size Generalized Predictive Control,” Energies, vol. 14, no. 1, p. 207, 2021, doi: 10.3390/en14010207.

A. Farzan Moghaddam, and A. Van den Bossche, “An Efficient Equalizing Method for Lithium-Ion Batteries Based on Coupled Inductor Balancing,” Electronics, vol. 8, no. 2, p. 136, 2019, doi: 10.3390/electronics8020136.

Z. C. Gao, C. S. Chin, W. D. Toh, J. Chiew, and J. Jia, “State-of-Charge Estimation and Active Cell Pack Balancing Design of Lithium Battery Power System for Smart Electric Vehicle,” Journal of Advanced Transportation, Art. no. 6510747, 14 p., 2017, doi: 10.1155/2017/6510747.

S. Narayanaswamy, M. Kauer, S. Steinhorst, M. Lukasiewycz, and S. Chakraborty, “Modular Active Charge Balancing for Scalable Battery Packs,” IEEE Transactions on Very Large Scale Integration (VLSI) Systems, vol. 25, no. 3, pp. 974–987, Mar. 2017, doi: 10.1109/TVLSI.2016.2611526.

L. Li, Z. Li, J. Zhao, and W. Guo, “Lithium-ion battery management system for electric vehicles,” International Journal of Performability Engineering, vol. 14, no. 12, pp. 3184–3194, 2018, doi: 10.23940/ijpe.18.12.p28.31843194.

D. Lee, S. Kang, and C. B. Shin, “Modeling the Effect of Cell Variation on the Performance of a Lithium-Ion Battery Module,” Energies, vol. 15, no. 21, p. 8054, 2022, doi: 10.3390/en15218054.

P. S. Babu, and K. Ilango, “Comparative Analysis of Passive and Active Cell Balancing of Li Ion Batteries,” in Proc. 3rd Int. Conf. Intelligent Computing Instrumentation and Control Technologies (ICICICT), Kannur, India, 2022, pp. 711–716, doi: 10.1109/ICICICT54557.2022.9917778.

W. Jiang, and F. Zhou, “Active Battery Balancing System for High Capacity Li-Ion Cells,” Energies, vol. 18, no. 23, p. 6371, 2025, doi: 10.3390/en18236371.

C. Wei, and X. Li, “Review of Bidirectional DC-DC Converters for Electric Vehicle Energy Management Systems,” in Proc. 7th Int. Conf. Smart Grid and Smart Cities (ICSGSC), Lanzhou, China, 2023, pp. 432–436, doi: 10.1109/ICSGSC59580.2023.10319186.

A. Farzan Moghaddam, and A. Van den Bossche, “A Ćuk Converter Cell Balancing Technique by Using Coupled Inductors for Lithium-Based Batteries,” Energies, vol. 12, no. 15, p. 2881, 2019, doi: 10.3390/en12152881.

V. Chandran, C. K. Patil, A. Karthick, D. Ganeshaperumal, R. Rahim, and A. Ghosh, “State of Charge Estimation of Lithium-Ion Battery for Electric Vehicles Using Machine Learning Algorithms,” World Electric Vehicle Journal, vol. 12, no. 1, p. 38, 2021, doi: 10.3390/wevj12010038.

H. Wu, H. Zhao, J. Yang, D. Qin, and J. Chen, “Battery Active Grouping and Balancing Based on the Optimal Energy Transfer Direction,” Sustainability, vol. 17, no. 11, p. 5219, 2025, doi: 10.3390/su17115219.

X. Dorronsoro, E. Garayalde, U. Iraola, and M. Aizpurua, “Modular battery energy storage system design factors analysis to improve battery-pack reliability,” Journal of Energy Storage, vol. 54, p. 105256, 2022, doi: 10.1016/j.est.2022.105256.

A. Tuluhong, Z. Xu, Q. Chang, and T. Song, “Recent Developments in Bidirectional DC-DC Converter Topologies, Control Strategies and Applications in Photovoltaic Power Generation Systems: A Comparative Review and Analysis,” Electronics, vol. 14, no. 2, p. 389, 2025. doi: 10.3390/electronics14020389.

D. O. Lipko, Device for Monitoring Battery Parameters, M.Sc. thesis, Dept. Micro- and Nanosystems Technology, Kyiv Polytechnic Institute, Kyiv, Ukraine, 77 p. [Online]. Available: https://ela.kpi.ua/handle/123456789/38755.
