The electrocurrent microrelay modelling

  • N. I. Mukhurov B. I. Stepanov Institute of Physics of NASB, Minsk, Belarus
  • G. I. Yefremov B. I. Stepanov Institute of Physics of NASB, Minsk, Belarus
  • S. P. Zhvavyi B. I. Stepanov Institute of Physics of NASB, Minsk, Belarus
Keywords: micro-electro current, planar structure, current, electromagnetic and reactive power

Abstract

The design and method of electrocurrent microrelay theoretical modelling is offered. It is established, that base function in the normalized kind graphically represents a symmetric parabola. Microrelay capability evaluation have been carried out for different current flow directions through the meander-line system of planar structure.

Published
2011-06-28
How to Cite
Mukhurov, N. I., Yefremov, G. I., & Zhvavyi, S. P. (2011). The electrocurrent microrelay modelling. Technology and Design in Electronic Equipment, (3), 6-9. Retrieved from https://www.tkea.com.ua/index.php/journal/article/view/TKEA2011.3.06
Issue
No. 3 (2011): Tekhnologiya i konstruirovanie v elektronnoi apparature
Section
Articles
