Obtaining a digital filter structure from state-space description

  • V. S. Sitnikov Odessa National Polytechnic University, Ukraine
  • P. V. Stupen Odessa National Polytechnic University, Ukraine
  • I. V. Baderko Odessa National Polytechnic University, Ukraine
Keywords: digital filter, state space, filter structure, eliminating ambiguity, ladder structure, lattice structure, rounding noise

Abstract

The paper considers the process of transforming a digital filter structure based on state-space representation. The problem of eliminating ambiguity in the system of equations is highlighted. Transformations are performed using the example of ladder and lattice (bridge) structures of a 2nd-order digital filter. The magnitude of output rounding noise is determined.

Published
2002-10-30
How to Cite
Sitnikov, V. S., Stupen, P. V., & Baderko, I. V. (2002). Obtaining a digital filter structure from state-space description. Technology and Design in Electronic Equipment, (4–5), 21-23. Retrieved from https://www.tkea.com.ua/index.php/journal/article/view/TKEA2002.4-5.21
Issue
No. 4–5 (2002): Tekhnologiya i konstruirovanie v elektronnoi apparature
Section
Articles

Copyright (c) 2002 Sitnikov V. S., Stupen P. V., Baderko I. V.

Creative Commons License

This work is licensed under a Creative Commons Attribution 4.0 International License.
